Class List Management

Source: vignettes/class-management.Rmd
class-management.Rmd

Understanding and managing your class list is important for maintaining consistent annotations.

Why Class Indices Matter (ifcb-analysis Users)

Note: This section is primarily relevant if you use the ifcb-analysis MATLAB toolbox (Sosik & Olson, 2007). If you only work with CSV exports, class indices are less critical.

IFCB .mat annotations use numerical indices to reference classes:

Index 1 → unclassified
Index 2 → Ciliate
Index 3 → Dinoflagellate
Index 4 → Diatom
...

When you save an annotation as a .mat file for ifcb-analysis, the file stores:

  • ROI number: 00042
  • Class index: 2 (meaning “Ciliate”)

If you change the order or remove classes, existing .mat annotations become invalid for ifcb-analysis!

Creating a Class List from Scratch

You can create a new class list directly in the app without uploading a file:

Class list editor for adding, removing, and reordering classes.

Class list editor for adding, removing, and reordering classes. Click to enlarge.

  1. Open Settings → Edit Class List
  2. The editor opens with an empty class list
  3. Add classes using either method:

Method 1 - One at a time:

  • Type a class name in the “Add new class” field
  • Click Add to End
  • Repeat for each class

Method 2 - Bulk entry:

  • Type or paste class names in the text area (one per line)
  • Click Apply Changes
  1. The app creates a temporary class list file automatically
  2. Save your work: Click Save as .mat or Save as .txt to keep your class list for future sessions

Note: The temporary class list works for the current session, but you should save it to a file for future use.

Loading an Existing Class List

From MAT File

Standard MATLAB class2use format:

  1. Open Settings
  2. Click Browse next to “Class List File”
  3. Select your .mat file

Note: Reading .mat files requires Python (via iRfcb).

From Text File

One class per line:

unclassified
Ciliate
Dinoflagellate
Diatom

Viewing Classes

  1. Open Settings → Edit Class List
  2. The left panel shows all classes with indices
  3. Toggle By ID / A-Z to sort the view

Note: Sorting is for viewing only - it doesn’t change actual indices.

Editing Classes

Renaming a Class

You can safely rename classes without breaking annotations:

  1. Find the class in the edit text area
  2. Change the name
  3. Click Apply Changes

The index stays the same, so existing annotations remain valid.

Adding New Classes

New classes must go at the end of the list:

Method 1 - Quick Add:

  1. Type name in “Add new class” field
  2. Click Add to End

Method 2 - Text Edit:

  1. Add new classes at the bottom of the text area
  2. Click Apply Changes

What NOT to Do (ifcb-analysis Users)

Note: These restrictions apply if you export .mat files for use with ifcb-analysis. CSV exports store class names directly and are not affected by index changes.

  • Never remove classes - This shifts all subsequent indices
  • Never reorder classes - This changes index-to-name mapping
  • Never insert in the middle - This shifts indices below

Example: What Goes Wrong (ifcb-analysis)

Original list:

1: unclassified
2: Ciliate
3: Dinoflagellate
4: Diatom

If you remove “Ciliate”:

1: unclassified
2: Dinoflagellate  ← Was index 3, now index 2!
3: Diatom  ← Was index 4, now index 3!

Now all your “Ciliate” (index 2) .mat annotations become “Dinoflagellate” when loaded in ifcb-analysis!

Exporting Class Lists

Save as MAT

Creates MATLAB-compatible class2use.mat for use with ifcb-analysis:

  1. Click Save as .mat
  2. Choose location in browser download

Note: Saving .mat files requires Python with scipy.

Save as TXT

Creates simple text file:

  1. Click Save as .txt
  2. Choose location in browser download

Best Practices

  1. Backup your class list before making changes

  2. Add classes at the end only (required for ifcb-analysis compatibility)

  3. Never delete - mark deprecated classes with prefix like “OLD_” (for ifcb-analysis users)

  4. Document changes in your project notes

  5. Use consistent naming - decide on convention (underscores, capitalization)

Tip: If you don’t use ifcb-analysis and only work with CSV exports, you have more flexibility with class list management since CSV files store class names directly.

Class Naming Conventions

Allowed Characters

Most characters commonly used in taxonomic names are allowed:

  • Letters (a-z, A-Z)
  • Numbers (0-9)
  • Underscores (_)
  • Hyphens (-) - e.g., “Strombidium-like”
  • Periods (.)
  • Spaces

Characters That Are Modified

Since class names are used as folder names when exporting PNGs, some characters are automatically sanitized:

Character Why What Happens
/ or \ Path separators would create subdirectories Replaced with _
< > " ' & HTML/security risks Removed
: * ? \| Invalid on Windows Removed
.. Path traversal security risk Removed

Example for ambiguous taxa: If you have Snowella/Woronichinia in your class list, it will be saved as Snowella_Woronichinia. The app will display a message when this happens.

Merging Class Lists

If you need to combine class lists from different projects:

  1. Export both as text files
  2. Manually merge, keeping original indices
  3. Add new classes at the end
  4. Import merged list

Special Classes

“unclassified”

  • Usually index 1 or at the end
  • Used for images below confidence threshold
  • Used for images you can’t identify

Detritus/Artifacts

Consider having classes for:

  • detritus
  • bubble
  • bad_image
  • multiple_organisms
